機械重型臥式車床
收藏
商品說明
產品概述 Product Description CG系列重型臥式車床為我公司根據長期生產臥車的經驗,采用國際上先進的設計手段和制造技術,執行國家現行最新精度標準,精心設計的一種集電氣、自動控制、液壓控制和現代機械設計等多學科、多門類的精密制造技術為一體的機電一體化機床產品。機床結構性能適用,機床具有動靜態剛度高、使用壽命長、加工效率高、各項功能安全可靠、操作方便和造型美觀等特點。 1、CG系列重型臥式車床適用于高速鋼、硬質合金鋼等刀具,對黑色金屬、有色金屬和部分非金屬的軸類、圓筒類和盤類零件,進行車削外圓、端面、切槽、切斷、鏜孔等 2、CG系列重型臥式車床主傳動與進給傳動采用分離式結構。 3、CG系列重型臥式車床床身采用整體三導軌,床身導軌采用磨削加工或鑲鋼結構的低磨擦副滑動平導軌。 4、CG系列重型臥式車床的主傳動由直流電機驅動,經機械三檔變速,實現主軸的轉速范圍。 5、主軸箱主軸為穿軸式結構,采用高精度可調徑向間隙的雙列短圓柱滾子軸承,經優化設計采用較大的主軸直徑及最佳支承跨距,提高了主軸的回轉精度和動、靜剛度。主軸上的頂尖采用法蘭式短錐柄結構,提高了頂尖與主軸的連接剛度。 6、刀架橫向采用梯形絲杠或滾珠絲杠,縱向采用高精度齒條及雙齒棒消隙結構,提高了刀架的傳動精度。 7、尾座為整體箱形結構,套筒內的芯軸采用高精度可調徑向間隙的雙列短圓柱滾筒內的芯軸采用高精度可調徑向間隙的雙列短圓柱滾子軸承,頂尖為法蘭式短錐柄頂尖,使尾座具有很高的剛度,套筒和尾座均為機動,并裝有液壓測力裝置。 8、可根據用戶要求,提供雙刀架、銑鏜裝置、磨削裝置、冷卻液裝置等。 CG series heavy duty horizontal lathe is an electromechanical machine tool integrating electrical control, hydraulic control, modern machinery design and other disciplines, Our heavy duty horizontal lathe executes national lastest accuracy standard, which is designed and manufactured according to the international advanced technology and our many years experience. This kind of horizonta lathe has a perfect structure performance with high rigidity, longer service life, higher efficiency, safe and stable function with easy operation. 2.Main transmission and feed transmission of CG series heavy duty horizontal lathe adopts separate structures. 5.The main shaft of headstock is a cross-axle structure, which adopts double-row short cylindrical roller bearing with high precision and adjustable radial clearance. and adopts a larger spindle diameter and the best supporting span through optimization design, which improves the rotary accuracy and dynamic and static stiffness of the spindle.The center on the spindle adopts the flange type short taper shank structure, which improves the connection rigidity between the center and the spindle. 7.The tailstock is a kind of intergal box structure, the inner shaft adopts double-row short cylindrical roller bearing with high precision and adjustable radial clearance, and the center is a kind of flange type short taper shank, so that the tailstock has high rigidity. The sleeve and tailstock are both automatic and driven by the motor and equipped with hydraulic force measuring device. 8.This kind of heavy duty horizontal lathe can be also installed double cutting tool carriages, milling & boring device, and cooling device. 產品實拍 Product Pictures 產品尺寸 Product Dimensions 產品參數 Datas
|
